Closed loop control with built-in PID regulator.
Through the keypad, parameter settings can be copied to another AC motor drive.

failure rate: < 0.15%, just the same as other world-class traditional brands, such as Siemens, ABB, Danfoss, Emerson, Schneider, Allen Bradley, Lenze, Yaskawa, Mitsubishi, Omron, Fuji, Hitachi, Toshiba, WEG, Bosch Rexroth
authorized CE, issued by ECMG
18-month warranty period
prompt delivery lead time: 1-3 days
supply to REGAL, Ingersoll Rand, Tata group, Foxconn...

You will be interested in more V&T EcoDriveCN® motor soft starters, variable speed drives, explosion proof drives, AC/DC reactors, du/dt filters, harmonic filters...



Application areas:
Rayon spinning, conveyor belt, extruder machines, plastic extrusion machinery, agitators, centrifuge, paper, pulp, sugar industry (separation of sugar from juice, retrofitting of sugar squeezer), air compressors, pump, fan, textile manufacturing, packaging technique, winding machinery, semiconductor manufacturing, handling, process engineering, chillers, escalators, conveyors, ball mills, die grinder, tobacco reprocessing process, tube making machine, cooling water circulation pumps in iron and steel plant, dedusting fan in iron and steel works.


E5-H-4T90G three-phase 380VAC-480VAC scalar control & vector control universal vvvf drive for constant torque/heavy-duty application

Power(KW)		0.75	1.5	2.2	3.7	5.5	7.5	11	15	18.5	22	30	37	45	55	75
Motor Power(KW)		0.75	1.5	2.2	3.7	5.5	7.5	11	15	18.5	22	30	37	45	55	75
Output	Voltage(V)	Three-phase 0V to rated input voltage
	Rate current(A)	2.5	3.8	5.5	9	13	17	24	30	39	45	60	75	91	112	150
	Overload capability	150% 1 minute, 180% 10 seconds, 200% 0.5 second, interval: 10 minutes (inverse time lag feature)
Input	Rated voltage/frequency	Three-phase 380V/480V; 50Hz/60Hz
	Allowable voltage range	323V ~ 528V; Voltage unbalancedness <=3%; allowable frequency fluctuation: +-5%
	Rate current(A)	3.5	6.2	9.2	14.9	21.5	27.9	39	50.3	60	69.3	86	104	124	150	201
Braking unit		Built-in as standard								External braking unit needed
Protection class		IP20 (NEMA 1). IP65 is optional.
Cooling mode		Self-cooling		Forced air cooling

Power(KW)		90	110	132	160	200	220	280	315	355	400	..	..	..	..	..
Motor Power(KW)		90	110	132	160	200	220	280	315	355	400
Output	Voltage(V)	Three-phase 0V to rated input voltage
	Rate current(A)	176	210	253	304	377	415	520	585	650	740
	Overload capability	150% 1 minute, 180% 10 seconds, 200% 0.5 second, interval: 10 minutes (inverse time lag feature)
Input	Rated voltage/frequency	Three-phase 380V/480V; 50Hz/60Hz
	Allowable voltage range	323V ~ 528V; Voltage unbalancedness <=3%; allowable frequency fluctuation: +-5%
	Rate current(A)	160*	196*	232*	282*	352*	385*	491*	552*	624*	704*
Braking unit		External braking unit needed
Protection class		IP20 (NEMA 1). IP65 is optional.
Cooling mode		Forced air cooling

Power(KW)		90	110	132	160	200	220	280	315	355	400	..	..	..	..	..
Motor Power(KW)		90	110	132	160	200	220	280	315	355	400
Output	Voltage(V)	Three-phase 0V to rated input voltage
	Rate current(A)	176	210	253	304	377	415	520	585	650	740
	Overload capability	150% 1 minute, 180% 10 seconds, 200% 0.5 second, interval: 10 minutes (inverse time lag feature)
Input	Rated voltage/frequency	Three-phase 380V/480V; 50Hz/60Hz
	Allowable voltage range	323V ~ 528V; Voltage unbalancedness <=3%; allowable frequency fluctuation: +-5%
	Rate current(A)	160*	196*	232*	282*	352*	385*	491*	552*	624*	704*
Braking unit		External braking unit needed
Protection class		IP20
Cooling mode		Forced air cooling

V&T EcoDriveCN® 380V ~ 480V (380V, 400V, 415V, 420V, 440V, 460V, 480V) 90KW and larger power better V/F control & vector control variable voltage variable frequency (VVVF) drives are configured with DC reactor (motor choke) as standard.
