V5-H sensorless vector control variable frequency drive (VFD)

vector control VFD
V5-H high performance general purpose vector control variable frequency drives (frequency inverters)

description     Model     technical      Installation     Applications     Documents      images

V&T EcoDriveCN® V5-H series superior quality sensorless vector control (field-oriented control) variable frequency drive (VFD) is based on high performance vector control technology.

Built-in PID feedback control, process control utilising the PID loops.
With the keypad, built-in parameter copy function from one drive to another.

failure rate: < 0.15%, just the same as other world-class traditional brands, such as Siemens, ABB, Emerson, Schneider, Rockwell Automation (Allen-Bradley), Bosch Rexroth, Lenze, Parker, Yaskawa, Mitsubishi, Omron, Fuji, Hitachi, Toshiba, WEG
authorized CE, issued by ECMG
delivery lead time: 1-3 days
With audit of NVLAP. NVLAP Lab code: 200068-0. ISO/IEC 07025:1999, ISO 9002:1994
supply to REGAL, Ingersoll Rand, Foxconn, Tata Group...

EcoDriveCN VSD for mixer

Voltage range:
200 VAC - 240 VAC (180 VAC - 260 VAC): 200 V, 208V, 220 V, 240V
380 VAC - 480 VAC (323 VAC - 528 VAC): 380 V, 400 V, 415 V, 440 V, 460 V, 480 V
500 VAC, 525 VAC, 550 VAC, 575 VAC, 600 VAC
690 VAC - 790 VAC (587 VAC - 793 VAC)
800 VAC, 900 VAC, 1000 VAC, 1140 VAC, 1200 VAC (960 VAC - 1300 VAC)

Power rating:
0.4 KW ~ more than 3000 KW (0.5 hp to more than 4000 hp)

PID closed loop control.

 Vector Control 1 (optimized V/F control):
 Offering excellent vector control performance and insensitive to motor parameters.
 Startup torque: 0.50Hz 180% rated torque
 Speed adjustment range: 1:100
 Speed stabilization precision: +- 0.5%
 0.50Hz controllable motor stable operation with 150% rated torque (large torque at low frequency).

 Vector Control 2 (Without encoder speed feedback, sensorless vector control, field oriented control):
 Precise speed sensorless vector control technology realizes AC motor decoupling, enabling the DC motorization of operation control.
 Startup torque: 0.25Hz 180% rated torque (large torque at low frequency)
 Speed adjustment range: 1:200
 Speed stabilization precision: +- 0.2%
  0.25Hz controllable motor stable operation with 150% rated torque.

mechanics, winders, screw feeders, electronics, laminating machine (laminator), dividing and cutting machines (splitting machines, slitting machines), metallurgy, mining and coal, air compressor, petrochemical, transportation, building materials, metal processing, textile, printing and dyeing, paper making, plastic injection moulding machine, central air conditioning, numerical control machine tools,fan and pump, blower, HVAC (air conditioner of large building, water supply system for large building), wastewater treatment (sewage disposal) system, civil engineering (municipal engineering), and other industrial areas.

Commitment to clients.

Comparison with other brands
